OVERVIEW ________________________________________ • Expand Your Wi-Fi Network for Ultimate Performance* • 450Mbps on 2.4GHz + 1300Mbps on 5GHz totals 1750Mbps Wi-Fi speeds* • Three adjustable external antennas provide optimal Wi-Fi coverage and reliable connections • Gigabit Ethernet port acts as a wireless adapter to connect a wired device to your network at gigabit speed • Intelligent signal light helps to find the best location for optimal Wi-Fi coverage by showing the signal strength • Works with any Wi-Fi router or wireless access point** ________________________________________ SPECIFICATION ________________________________________ HARDWARE FEATURES Plug Type • EU, UK, US Standards and Protocols • IEEE802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b Interface • 1 * 10/100/1000M Ethernet Port (RJ45) Button • RE (Range Extender) Button, Reset Button, LED Button, Power Button Power Consumption • 9W（max power consumption） Dimensions ( W x D x H ) • 6.4x 3.0 x 2.6 in. (163 x 76.4 x 66.5mm) Antenna • 3* external WIRELESS FEATURES Frequency • 2.4GHz & 5GHz(11ac) Signal Rate • 5GHz:Up to 1300Mbps • 2.4GHz:Up to 450Mpbs Reception Sensitivity 5GHz： • 11a 6Mbps:-93dBm@10% PER • 11a 54Mbps: -76dBm@10% PER • 11ac HT20 mcs8: -68dBm@10% PER • 11ac HT40 mcs9: -64dBm@10% PER • 11ac HT80 mcs9: -61dBm@10% PER 2.4GHz • 11g 54M: -77dBm@10% PER • 11n HT20 mcs7: -73dBm@10% PER • 11n HT40 mcs7: -70dBm@10% PER Wireless Modes • Range Extender Wireless Functions • Wireless Statistic • Concurrent Mode boost both 2.4G/5G WiFi band • High Speed Mode for great speed for HD Gaming and video • Access Control • LED Control • Domain Login Function Wireless Security • 64/128-bit WEP • WPA-PSK / WPA2-PSK Transmission Power • <20dBm(2.4GHz) • <23dBm(5GHz) OTHERS Certification • FCC, RoHS Package Contents • AC1750 Wi-Fi Range Extender RE450 • RJ-45 Ethernet Cable • Quick Installation Guide Box Dimensions (W X D X H) • 7.9 x 4.9 x 3.4in. (202x 125 x 86mm) System Requirements • Microsoft® Windows® 98SE, NT, 2000, XP, Vista or Windows 7, 8, 10, Mac® OS, NetWare®, UNIX® or Linux.
