• Interface 3 10/100 RJ45 LAN Ports 1 10/100/1000 RJ45 LAN/WAN Port 1 RJ11 Port 1 USB 2.0 Port • Button WPS Button Wireless On/Off Button Power On/Off Button Reset Button • Power Supply 12V/1.5A • IEEE Standards IEEE 802.3 IEEE 802.3u 802.3ab • VDSL2 Standards ITU G.993.2, Up to 17a pro¬le (POTS) ITU-T G.993.5 (G.vector) ITU-T G.998.4 (G.INP) • ADSL Standards Full-rate ANSI T1.413 Issue 2, ITU-T G.992.1(G.DMT), ITU-T G.992.2(G.Lite), ITU-T G.994.1 (G.hs), ITU-T G.995.1 • ADSL2 Standards ITU-T G.992.3 (G.DMT.bis), ITU-T G.992.4 (G.lite.bis) • ADSL2+ Standards ITU-T G.992.5 • Dimensions ( W x D x H ) 243.5×167.5×32.7mm • Antenna Type 3 ¬fixed external antennas • Frequency response 2.4GHz: 2.400~2.483 GHz 5GHz: 5.150~5.250 GHz • WIRELESS FEATURES • Wireless Standards IEEE 802.11a/n/ac 5GHz, IEEE 802.11b/g/n 2.4GHz • Wireless Speeds 867Mbps at 5GHz 300Mbps at 2.4GHz • Transmit Power 2.4GHz <20dBm(EIRP) 5GHz <23dBm(EIRP) • Wireless Functions Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics • Wireless Security 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA-PSK2 encryptions, Wireless MAC Filtering • Wireless Schedule Support 2.4GHz and 5GHz Wireless Schedule • SOFTWARE FEATURES • Quality of Service ATM QoS • Security NAT Firewall, Access Control, IP and MAC Address Binding • Operating Modes VDSL/ADSL Modem Router, Wireless Router,3G/4G Router • Management Web Based Con¬guration(HTTP), Remote management, command Line Interface, SSL for TR-069, SNMP v1/2c, Web Based Firmware Upgrade, Diagnostic Tools • DHCP Server, Client, DHCP Client List, Address Reservation, DHCP Relay • Port Forwarding Virtual Server, Port Triggering, DMZ, ALG, UPnP • Dynamic DNS DynDns, NO-IP • VPN Pass-Through PPTP, L2TP, IPSec Passthrough • Protocols Supports IPv4 and IPv6 • ATM/PPP Protocols ATM Forum UNI3.1/4.0, PPP over ATM (RFC 2364), PPP over Ethernet (RFC2516), IPoA (RFC1577/2225), MER\IPoE (RFC 1483 Routed), Bridge (RFC1483 Bridge), PVC – Up to 8 PVCs • Advanced Functions Parental Control, Network Address Translation(NAT), Port Mapping(Grouping), Static Routing, RIP v1/v2(optional), DNS Relay, DDNS, IGMP V1/V2/V3 • USB Sharing Support Samba(Storage)/FTP Server/Media Server/Printer Server, 3G/4G Modem • Guest Network 2.4GHz guest network, 5GHz guest network • IPSec VPN Supports up to 10 IPSec VPN tunnels • Beamforming 5GHz • OTHERS • Certification CE, RoHS, RCM • Package Contents · AC1200 Wireless VDSL/ADSL Modem Router Archer VR400 · External Splitter · RJ11 DSL Cable · RJ45 Ethernet Cable · Power Adapter · Quick Installation Guide • System Requirements · Microsoft Windows XP/7/8/8.1/10, MAC OS, NetWare, UNIX or Linux · Internet Explorer, Firefox, Chrome, Safari or other Java-enabled browser · Subscription with an Internet Service Provider (for Internet access) • Environment · Operating Temperature: 0℃~40℃ (32℉ ~104℉) · Storage Temperature: -40℃~70℃ (-40℉ ~158℉) · Operating Humidity: 10%~90% non-condensing · Storage Humidity: 5%~90% non-condensing
