SilverStone Strider 750 EF 80+ Non-Modular ATX Power Supply
Sold by
Viewnet Computers
- High efficiency with 80 PLUS certification
- Robust reliability and protection design
- 24/7 continuous power output with 40℃ operating temperature
- Class-leading single +12V rail
- Sleek and flexible black flat cable design
- Silent running 120mm fan with 18dBA
Specification
Product No. SST-ST750-EF Model (safety certification) SST-AX0750FCWH-A Color Black (lead-free paint) Max. DC Output 750W Power density 415W per liter Load Range
Output +3.3V +5V +12V +5VSB -12V Max.(Amps) 18A 18A 41A 2.5A 0.4A Peak (Amps) / / / / / Min.(Amps) 0.1A 1A 2A 0A 0A Range (%) ±5% ±5% ±5% ±5% ±10% Line Reg.(%) ±1% ±1% ±1% ±1% ±1% Ripple(mVp-p) 50mV 50mV 120mV 50mV 120mV Combined +3.3V & +5V 100W Combined +12V 672W Input Voltage 180 ~ 264 Vrms Input Frequency Range 47Hz ~ 63Hz PFC Active PFC (PF>0.9 at full load) Efficiency 82% ~ 85% (at 20% ~ 100% loading) MTBF 100,000 hours Operating temperature 0°C ~ 40°C Protection Over Voltage Protection
Under Voltage Protection
Over Power Protection
Short Circuit Protection Connectors 1 x 24 / 20-Pin motherboard connector
2 x 8 / 4-Pin EPS / ATX 12V connectors
4 x 8 / 6-Pin PCIe connectors
6 x SATA connectors
2 x 4-Pin Peripheral connectors Cooling System Silent 120mm fan Noise Level 18 dBA minimum Certification 80 PLUS Form factor ATX (PS2) Dimension 150mm (W) × 86mm (H) × 140mm (D)
5.91″ (W) x 3.39″ (H) x 5.5″ (D) Weight 1.48 kg
