Game, stream, create. The GeForce RTX 4060 lets you take on the latest games and apps with the ultra-efficient NVIDIA Ada Lovelace architecture. Experience immersive, Al-accelerated gaming with ray tracing and DLSS 3, and supercharge your creative process and productivity with NVIDIA Studio.

Specification

GPU Engine Specs CUDA Cores 3072 Boost Clock (MHz) 2490 MHz Base Clock (MHz) 1830 MHz
Thermal and Power Spec Minimum System Power Requirement (W) 550W Supplementary Power Connectors 1x PCIe 8-pin cables

Memory Specs Memory Clock 17Gbps Standard Memory Config 8GB Memory Interface GDDR6 Memory Interface Width 128-bit Memory Bandwidth (GB/sec) 272 GB/sec

Feature Support Real-Time Ray Tracing Yes Ray Tracing Cores 3rd Generation Tensor Cores 4th Generation NVIDIA Architecture Ada Lovelace Microsoft DirectX 12 Ultimate NVIDIA DLSS 3 PCI Express Gen 4 Yes NVIDIA GeForce Experience Yes NVIDIA Ansel Yes NVIDIA FreeStyle Yes Bus Support PCI-E 4.0 X16 NVIDIA ShadowPlay Yes OS Certification Windows 11 / 10, Linux, FreeBSDx86 NVIDIA Highlights Yes NVIDIA G-SYNC™-Ready Yes Game Ready Drivers Yes NVIDIA Studio Drivers Yes NVIDIA GPU Boost™ Yes Vulkan API Yes OpenGL 4.6 DisplayPort 1.4a Yes NVIDIA Encoder 2x 8th Generation NVIDIA Decoder 5th Generation HDMI 2.1a Yes

Accessories Installation Guide Yes Power Guide Yes

Card Dimensions Length 250mm Height 118mm Width 42mm

Display Support Multi Monitor Yes Maxmium Digital Resolution 7680×4320 HDCP 2.3 Standard Display Connectors HDMI 2.1a, 3x DisplayPort 1.4a
