Display
• Diagonal Viewing Size
54.61 cm
21.5 Inches

Aspect Ratio
(16:9)

Panel Type
Twisted Nematic

Preset Display Area (H x V)
476.06 mm x 267.79 mm
18.74" x 10.54"
127484.10 mm² (197.52 inches²)

Maximum Preset Resolution
1920 x 1080 at 60Hz

Contrast Ratio
1000:1 (typical)

Brightness
250 cd/m² (typical)

Response Time
5 ms typical (Black to White)

Viewing Angle
160° vertical / 170° horizontal

Color Support
Color Gamut (typical): 84% (CIE 1976), 72% (CIE 1931)
Color Depth: 16.7 Million colors

Pixel Pitch
0.248 x 0.248 mm

Pixel Per Inch (PPI)
102
Wireless Charging Feature
NA

G-SYNC Support
NA

PbP / PiP
PbP (No)
PiP (No)

Backlight Technology
White LED

Display Type
Widescreen Panel Display

Display Screen Coating
Anti-Glare with 3H hardness

Audio Output
Optional Soundbar - (AC511) & (AE515)
Daisy Chain Availability
No

Dell Display Manager Compatibility
Yes

Remote Asset Management
Yes, via Dell Command Monitor

Color Calibration SDK SW
No

Color Calibration with X-rite colorimeter
No
________________________________________
Stand

Flat Panel Mount Interface
VESA (100 mm)
Connectivity
• 1 x HDMI (ver 1.4)
1 x VGA
Adjustability

Tilt (-5° to 21°)
Built in cable-management

Built-in Devices
N.A.
Security
• Security lock slot (cable lock sold separately)
Anti-theft stand lock slot (to panel)
Dimensions & Weight
• Height with stand
396.7 mm
15.62"
Width with stand
512.2 mm
20.17"
Depth with stand
180.0 mm
7.09"
Width without stand
512.2 mm
20.17"
Height without stand
303.7 mm
11.96"
Depth without stand
50.5 mm
1.99"
Weight (panel only - for VESA mount)
2.84 kg
6.26 lb
Weight (with packaging)
4.85 kg
10.69 lb
Power
• Voltage Required
100 VAC to 240 VAC / 50 Hz or 60 Hz ± 3 Hz / 1.5 A (typical)

Power Consumption (Operational)
18W (typical) /24W (maximum)6

Power Consumption Stand by / Sleep
Less than 0.3 W
Environmental
• Temperature Range
Operating: 0° to 40°C (32° to 104°F)
Non-operating: -20° to 60° (-4° to 140° F)

Humidity Range
Operating: 10% to 80% (non-condensing)
Non-Operating: 5% to 90% (non-condensing)

Altitude Operating
Operating: 5,000 m (16,404 ft) max
Non-Operating: 12,191 m (40,000 ft) max
