Specification
Model MPZ-D001-AFBAPV
PFC Active PFC
ATX Version ATX 12V
Input Voltage 110-240V
Input Current 15-8A
Input Frequency 50-60Hz
Dimensions (L x W x H) 201.2 x 150 x 86 mm
Fan Size 135mm
Fan Bearing TBB
Efficiency 92% Typical Load
80 PLUS Rating 80 PLUS Platinum
ErP 2014 Lot 3 Yes
Operating Temperature 0-50°C
MTBF >100,000 Hours
Protections OVP, OPP, SCP, OCP, UVP, OTP
Regulatory cTUVus, TUV, CE, CCC, FCC, EAC, RCM, BSMI, KC
ATX 24-Pin Connectors 1
EPS 4+4 Pin Connectors 1
EPS 8 Pin Connector 1
SATA Connectors 16
Peripheral 4-Pin Connectors 8
FDD Cable 4-Pin Connectors 1
PCI-e 6+2 Pin Connectors 12
Wattage Above 750W
80 Plus Platinum
Modular Full Modular
Series V Platinum Series
